Wall mounted cylinder
SHZ 30 S (GB)

  • Product details

    Price conscious hot water provision.

    In wall mounted cylinders, the amount of standby power consumed greatly influences the operating costs over time. Thanks to its exceptional insulation, this wall mounted cylinder offers terrific hot water convenience at an affordable price.

    Simple yet effective.

    The easy to use control element enables variable temperature adjustment, while the individual LEDs provide information on the heat amount currently stored.



    ERP product datasheet
    Reach-Information
    UK ERP product datasheet
    Technical datasheet

    Product Number: 232783

    Connected load ~ 230 V: 1-4 kW

    Power supply: 1/N/PE

    Rated voltage: 230 V

    Frequency: 50 Hz

    Load profile: S

    Energy efficiency class: B

    Standby energy consumption/24 h at 65 °C: 0.52 kWh

    Nominal capacity: 30 l

    Mixed water amount at 40 °C: 50 l

    Temperature setting range: 35-70 °C

    Max. flow rate: 18 l/min

    Height: 846 mm

    Width: 410 mm

    Depth: 420 mm
